The S&M THD Street Frame was designed to replace the Holy Diver Frame. The new THD utilizes a very street friendly geometry with its steeper headtube, shorter chain stays, and higher bottom bracket. S&M also added 1/4" thick heated treat dropouts to conquer any concrete ledge.
- .049” straight-gauge ThermalX downtube to resist denting
- Brakeless only
- Street geometry
| REAR END LENGTH | 12.7″-13″ |
| HEAD TUBE ANGLE | 75.5° |
| HEAD TUBE STYLE | 5″ Integrated (45°/45°, 41.8mm) |
| SEAT TUBE ANGLE | 71° |
| SEAT CLAMP | Investment Cast |
| SEAT POST SIZE | 1″ (25.4mm) |
| BB HEIGHT | 11.7″ |
| BB STYLE | Mid |
| STANDOVER HEIGHT | 9.25″ |
| BRAKE MOUNTS | No Brake Mounts |
| DROPOUTS | 14mm Slot, 4Q-Baked |
| GYRO TABS | None |
| WEIGHT | 20.75″ TT 5.1 lb (2.31 kg) |
